Electronic laboratory block heater RT-A19
Razılaşma ilə
Feature | Specification |
---|---|
Operating Temperature Range | (-10 °C) – (+80 °C) |
Capacity (Internal Volume) | 125 L |
Thermoelement Type | Pt – 100 |
Temperature Control | PID Digital Control |
Load Switching Element | SSR |
Thermostat Adjustment Sensitivity | 0.1 °C |
Thermostat Operating Accuracy | ± 0.1 °C |
Thermometer Reading Sensitivity | 0.1 °C |
Internal Temperature Variations | ± 1 °C |
Refrigerant Type | R134a |
Circulation Fan | Available |
Observation Window on Door | Available |
Internal Chamber Illumination | Available |
Safety System (Heating) | Liquid Expansion Safety Thermostat (30-90 °C) |
External Cabinet Material | Electrostatic Oven Painted Steel |
Internal Chamber Material | Stainless Steel |
Insulation Material | Rock Wool |
Shelf | PVC Coated Steel Wire (2 pieces) |
Fuse | 16 Amps |
Total Power | 950 W |
Power Supply | AC 190-240 V / 50-60 Hz |
Internal Dimensions (W x D x H) | 50 x 50 x 50 cm |
External Dimensions (W x D x H) | 65 x 65 x 97 cm |
Net Weight | 83 kg |
Packaged Weight | 100 kg |
